Air-Cooled Condenser THC Series

Air-Cooled Condenser Heat Rejection 5 - 76 kW

Air Cooled Condensers

Contact Us

Specification
Download

แบบไม่มีพัดลมระบายความร้อน

Model	Heat Rejection (kW)	Connection (Inch)		Fan Motor		Size
Model	Heat Rejection (kW)	In	Out	Blade x Qty. (mm.)	Current x Qty. (A)	W	L	H
THC 140	-	5/8	1/2	-	-	250	635	470
THC 180	-	5/8	1/2	-	-	250	635	520
THC 210	-	5/8	1/2	-	-	302	635	520
THC 290	-	5/8	1/2	-	-	302	736	622
THC 360	-	5/8	1/2	-	-	302	990	673
THC 440	-	3/4	1/2	-	-	302	990	673
THC 450	-	3/4	1/2	-	-	250	1117	622
THC 470	-	3/4	1/2	-	-	330	990	673
THC 500	-	3/4	1/2	-	-	302	1117	622
THC 530	-	3/4	1/2	-	-	330	990	826
THC 630	-	7/8	5/8	-	-	302	1295	724
THC 660	-	7/8	5/8	-	-	330	990	876
THC 720	-	7/8	5/8	-	-	302	1295	724
THC 760	-	7/8	5/8	-	-	302	1498	826
THC 850	-	7/8	5/8	-	-	302	1498	826
THC 920	-	7/8	5/8	-	-	330	1498	826
THC 1060	-	7/8	5/8	-	-	330	1498	826
THC 1100	-	7/8	5/8	-	-	302	2172	826
THC 1170	-	1-1/8	3/4	-	-	330	1625	927
THC 1260	-	1-1/8	3/4	-	-	302	2172	826
THC 1320	-	1-1/8	3/4	-	-	330	1625	927
THC 1420	-	1-3/8	7/8	-	-	328	1675	1079
THC 1510	-	1-3/8	7/8	-	-	302	1498	1638
THC 1670	-	1-3/8	7/8	-	-	330	2413	927
THC 1700	-	1-3/8	7/8	-	-	302	1498	1638
THC 1840	-	1-3/8	7/8	-	-	330	1498	1638
THC 2000	-	1-3/8	7/8	-	-	330	2413	927
THC 2110	-	1-3/8	7/8	-	-	330	1498	1638
THC 2220	-	1-3/8	7/8	-	-	330	1498	1638

แบบมอเตอร์พัดลมรุ่นมาตรฐาน

Model	Heat Rejection (kW)	Connection (Inch)		Fan Motor		Size
Model	Heat Rejection (kW)	In	Out	Blade x Qty. (mm.)	Current x Qty. (A)	W	L	H
THC 140 Y	5.73	5/8	1/2	350 x 1	0.37 x 1	250	635	470
THC 180 Y	6.86	5/8	1/2	400 x 1	0.48 x 1	250	635	520
THC 210 Y	8.88	5/8	1/2	450 x 1	0.58 x 1	302	635	520
THC 290 Y	12.69	5/8	1/2	450 x 1	0.58 x 1	302	736	622
THC 360 Y	15.85	5/8	1/2	450 x 1	0.58 x 1	302	990	673
THC 440 Y	18.34	3/4	1/2	500 x 1	0.93 x 1	302	990	673
THC 450 Y	19.15	3/4	1/2	450 x 2	0.58 x 2	250	1117	622
THC 470 Y	19.51	3/4	1/2	500 x 1	0.93 x 1	330	990	673
THC 500 Y	21.67	3/4	1/2	450 x 2	0.85 x 2	302	1117	622
THC 530 Y	22.35	3/4	1/2	500 x 1	0.93 x 1	330	990	826
THC 630 Y	25.83	7/8	5/8	500 x 2	0.93 x 1	302	1295	724
THC 660 Y	26.62	7/8	5/8	630 x 1	1.95 x 1	330	990	876
THC 720 Y	29.25	7/8	5/8	500 x 2	0.93 x 2	302	1295	724
THC 760 Y	31.38	7/8	5/8	500 x 2	0.93 x 2	302	1498	826
THC 850 Y	35.56	7/8	5/8	500 x 2	0.93 x 2	302	1498	826
THC 920 Y	37.7	7/8	5/8	630 x 2	1.95 x 2	330	1498	826
THC 1060 Y	40.83	7/8	5/8	630 x 2	1.95 x 2	330	1498	826
THC 1100 Y	46.89	7/8	5/8	500 x 3	0.93 x 3	302	2172	826
THC 1170 Y	46.71	1-1/8	3/4	630 x 2	1.95 x 2	330	1625	927
THC 1260 Y	53.08	1-1/8	3/4	500 x 3	0.93 x 3	302	2172	826
THC 1320 Y	52.51	1-1/8	3/4	630 x 2	1.95 x 2	330	1625	927
THC 1420 Y	58.74	1-3/8	7/8	630 x 2	1.95 x 2	328	1675	1079
THC 1510 Y	62.78	1-3/8	7/8	500 x 4	0.93 x 4	302	1498	1638
THC 1670 Y	71.37	1-3/8	7/8	630 x 3	1.95 x 3	330	2413	927
THC 1700 Y	71.12	1-3/8	7/8	500 x 4	0.93 x 4	302	1498	1638
THC 1840 Y	75.38	1-3/8	7/8	630 x 4	1.95 x 4	330	1498	1638
THC 2000 Y	79.38	1-3/8	7/8	630 x 3	1.95 x 3	330	2413	927
THC 2110 Y	81.68	1-3/8	7/8	630 x 4	1.95 x 4	330	1498	1638
THC 2220 Y	85.51	1-3/8	7/8	630 x 4	1.95 x 4	330	1498	1638

แบบมอเตอร์พัดลมคุณภาพสูง

THC Catalogue

Tags: Coolscape Heat Rejection HR R-22 R-134A R-407C Fan Motor

Nearby Products

Air-Cooled Condenser THL-THLD Series (Horizontal)

Air-Cooled Condenser Heat Rejection 56 - 252 kW

แอร์คูล คอนเดนเซอร์ Air-Cooled Condenser THV-THVD Series

Air-Cooled Condenser Heat Rejection 62 - 701 kW

DANFOSS Thermostatic Expension Valves (TE2)

Cooling Capacity 1 - 20.5 kW

DANFOSS Orifice for Expansion Valves (TE5)

For TE5 to TE20

DANFOSS Orifice for Expansion Valves (TE2)

For TE2

Related Products

DANFOSS Compressor Type SC

5/16 - 3/4 HP

LU-VE Unit Cooler Type FHC

with Heater in coil / For small and large cold rooms

Model	Heat Rejection (kW)	Connection (Inch)		Fan Motor		Size
Model	Heat Rejection (kW)	In	Out	Blade x Qty. (mm.)	Current x Qty. (A)	W	L	H
THC 140 E	6.6	5/8	1/2	350 x 1	0.37 x 1	250	635	470
THC 180 E	7.89	5/8	1/2	400 x 1	0.44 x 1	250	635	520
THC 210 E	10.27	5/8	1/2	450 x 1	0.98 x 1	302	635	520
THC 290 E	14.6	5/8	1/2	450 x 1	0.98 x 1	302	736	622
THC 360 E	18.47	5/8	1/2	450 x 1	0.98 x 1	302	990	673
THC 440 E	21.23	3/4	1/2	500 x 1	1.86 x 1	302	990	673
THC 450 E	21.80	3/4	1/2	450 x 2	0.98 x 2	250	1117	622
THC 470 E	22.44	3/4	1/2	500 x 1	1.86 x 1	330	990	673
THC 500 E	24.83	3/4	1/2	450 x 2	0.98 x 2	302	1117	622
THC 530 E	26.09	3/4	1/2	500 x 1	1.86 x 1	330	990	826
THC 630 E	29.34	7/8	5/8	500 x 2	1.86 x 1	302	1295	724
THC 660 E	30.56	7/8	5/8	630 x 1	2.48 x 1	330	990	876
THC 720 E	33.53	7/8	5/8	500 x 2	1.86 x 2	302	1295	724
THC 760 E	35.66	7/8	5/8	500 x 2	1.86 x 2	302	1498	826
THC 850 E	41.21	7/8	5/8	500 x 2	1.86 x 2	302	1498	826
THC 920 E	42.82	7/8	5/8	630 x 2	2.48 x 2	330	1498	826
THC 1060 E	47.05	7/8	5/8	630 x 2	2.48 x 2	330	1498	826
THC 1100 E	53.66	7/8	5/8	500 x 3	1.86 x 3	302	2172	826
THC 1170 E	53.54	1-1/8	3/4	630 x 2	2.48 x 2	330	1625	927
THC 1260 E	61.16	1-1/8	3/4	500 x 3	1.86 x 3	302	2172	826
THC 1320 E	60.72	1-1/8	3/4	630 x 2	2.48 x 2	330	1625	927
THC 1420 E	68.21	1-3/8	7/8	630 x 2	2.48 x 2	328	1675	1079
THC 1510 E	71.32	1-3/8	7/8	500 x 4	1.86 x 4	302	1498	1638
THC 1670 E	81.37	1-3/8	7/8	630 x 3	2.48 x 3	330	2413	927
THC 1700 E	82.40	1-3/8	7/8	500 x 4	1.86 x 4	302	1498	1638
THC 1840 E	85.66	1-3/8	7/8	630 x 4	2.48 x 4	330	1498	1638
THC 2000 E	91.81	1-3/8	7/8	630 x 3	2.48 x 3	330	2413	927
THC 2110 E	94.11	1-3/8	7/8	630 x 4	2.48 x 4	330	1498	1638
THC 2220 E	101.11	1-3/8	7/8	630 x 4	2.48 x 4	330	1498
