แอร์คูล คอนเดนเซอร์ Air-Cooled Condenser THV-THVD Series
Air-Cooled Condenser Heat Rejection 62 - 701 kW
Air Cooled Condensers
Contact Us
มอเตอร์มาตรฐาน
| Model | Heat Rejection (kW) | Connection (Inch) | Fan Motor | Size | ||||
| In | Out | Blade x Qty. (mm.) | Current x Qty. (A) | W | L | H | ||
| THV 25 | 62 | 1-3/8 | 1-1/8 | 800 x 1 | 3.8 x 1 | 1170 | 1170 | 1448 |
| THV 29 | 69 | 1-3/8 | 1-1/8 | 800 x 1 | 3.8 x 1 | 1170 | 1170 | 1448 |
| THV 50 | 123 | 1-5/8 | 1-1/8 | 800 x 2 | 3.8 x 2 | 1170 | 2340 | 1448 |
| THV 58 | 139 | 1-5/8 | 1-1/8 | 800 x 2 | 3.8 x 2 | 1170 | 2340 | 1448 |
| THV 75 | 185 | 2-1/8 | 1-3/8 | 800 x 3 | 3.8 x 2 | 1170 | 3510 | 1448 |
| THV 87 | 208 | 2-1/8 | 1-3/8 | 800 x 3 | 3.8 x 2 | 1170 | 3510 | 1448 |
| THV 100 | 246 | 2-1/8 | 1-5/8 | 800 x 4 | 3.8 x 4 | 1170 | 4680 | 1448 |
| THV 116 | 277 | 2-1/8 | 1-5/8 | 800 x 4 | 3.8 x 4 | 1170 | 4680 | 1448 |
| Model | Heat Rejection (kW) | Connection (Inch) | Fan Motor | Size | ||||
| In | Out | Blade x Qty. (mm.) | Current x Qty. (A) | W | L | H | ||
| THVD 90 | 218 | 2-1/8 | 1-3/8 | 800 x 4 | 3.8 x 4 | 2340 | 2340 | 1942 |
| THVD 100 | 240 | 2-1/8 | 1-3/8 | 800 x 4 | 3.8 x 4 | 2340 | 2340 | 1942 |
| THVD 135 | 327 | 2-1/8 | 1-5/8 | 800 x 6 | 3.8 x 6 | 2340 | 3510 | 1942 |
| THVD 150 | 360 | 2-1/8 | 1-5/8 | 800 x 6 | 3.8 x 6 | 2340 | 3510 | 1942 |
| THVD 180 | 436 | 2-5/8 | 1-5/8 | 800 x 8 | 3.8 x 8 | 2340 | 4680 | 1942 |
| THVD 200 | 480 | 2-5/8 | 1-5/8 | 800 x 8 | 3.8 x 8 | 2340 | 4680 | 1942 |
| THVD 225 | 544 | 2-5/8 | 2-1/8 | 800 x 10 | 3.8 x 10 | 2340 | 5850 | 1942 |
| THVD 250 | 599 | 2-5/8 | 2-1/8 | 800 x 10 | 3.8 x 10 | 2340 | 5850 | 1942 |
มอเตอร์คุณภาพสูง
| Model | Heat Rejection (kW) | Connection (Inch) | Fan Motor | Size | ||||
| In | Out | Blade x Qty. (mm.) | Current x Qty. (A) | W | L | H | ||
| THV 29 EC | 73 | 1-3/8 | 1-1/8 | 910 x 1 | 2.09 x 1 | 1173 | 1318 | 1170 |
| THV 35 EC | 81 | 1-5/8 | 1-1/8 | 910 x 1 | 2.09 x 1 | 1173 | 1318 | 1170 |
| THV 58 EC | 144 | 1-5/8 | 1-3/8 | 910 x 2 | 2.09 x 2 | 1173 | 2488 | 1170 |
| THV 68 EC | 163 | 1-5/8 | 1-3/8 | 910 x 2 | 2.09 x 2 | 1173 | 2488 | 1170 |
| THV 87 EC | 216 | 2-1/8 | 1-3/8 | 910 x 3 | 2.09 x 3 | 1173 | 3658 | 1170 |
| THV 100 EC | 243 | 2-1/8 | 1-3/8 | 910 x 3 | 2.09 x 3 | 1173 | 3658 | 1170 |
| THV 120 EC | 288 | 2-1/8 | 1-5/8 | 910 x 4 | 2.09 x 4 | 1173 | 4828 | 1170 |
| THV 135 EC | 324 | 2-1/8 | 1-5/8 | 910 x 4 | 2.09 x 4 | 1173 | 4828 | 1170 |
| Model | Heat Rejection (kW) | Connection (Inch) | Fan Motor | Size | ||||
| In | Out | Blade x Qty. (mm.) | Current x Qty. (A) | W | L | H | ||
| THVD 100 EC | 255 | 1-3/8 | 1-1/8 | 910 x 4 | 2.09 x 4 | 1682 | 2488 | 2343 |
| THVD 120 EC | 281 | 1-5/8 | 1-1/8 | 910 x 4 | 2.09 x 4 | 1682 | 2488 | 2343 |
| THVD 165 EC | 383 | 1-5/8 | 1-3/8 | 910 x 6 | 2.09 x 6 | 1682 | 3658 | 2343 |
| THVD 185 EC | 421 | 1-5/8 | 1-3/8 | 910 x 6 | 2.09 x 6 | 1682 | 3658 | 2343 |
| THVD 210 EC | 510 | 2-1/8 | 1-3/8 | 910 x 8 | 2.09 x 8 | 1682 | 4828 | 2343 |
| THVD 230 EC | 526 | 2-1/8 | 1-3/8 | 910 x 8 | 2.09 x 8 | 1682 | 4828 | 2343 |
| THVD 260 EC | 636 | 2-1/8 | 1-5/8 | 910 x 10 | 2.09 x 10 | 1682 | 5998 | 2343 |
| THVD 290 EC | 701 | 2-1/8 | 1-5/8 | 910 x 10 | 2.09 x 10 | 1682 | 5998 | 2343 |
หมายเหตุ : ใช้ระบบไฟฟ้า 380V/3Ph/50Hz
EC = มอเตอร์พัดลมแบบคุณภาพสูง
REMARK: คำนวณค่า Heat Rejection ที่เงื่อนไข TD=12K, SH5K, SC5K
HR (Heat Rejection) หากต้องการหาค่า HR จากสารทำความเย็นชนิดอื่น
HR @ 12K TD = HR x 1.00 R-22 = HR x 1.00
HR @ 10K TD = HR x 0.82 R-134A = HR x 0.97
HR @ 8K TD = HR x 062 R-407C = HR x 1.04
THV-THVD Catalogue
